114
General Views of the Scales
FC6CCE-H(0CE), FC2CCE-S(0CE), FC12CCE-S(0CE), FC6CCE-S(0CE)
The “0CE” suffix appended to the model number indicates a verified or verifiable scale model
No. Designation Order no.
for replacement
1 Display and control unit
2 Load plate 69 LP0007
3 Glass draft shield cylinder
(depending on model) 69 LP0008
4 Leveling foot 69 B20005
5 Shock absorber 69 LP0010
6 Metrological ID label
(only on verified models or models acceptable
for legal metrological verification)
7 Tare key
8 Function keys
9 Print key
No. Designation Order no.
for replacement
10 Keys for numeric input
11 Toggle key for alphabetic input
12 On/off key
13 Weight display
14 Lug for attaching an antitheft
locking device
15 AC jack
16 Interface port
17 Level indicator
Not shown:
Dust cover for weighing platform 69 60FB02
Dust cover for display and control unit 69 60LP03
Protective caps and plugs (set) 69 B20009
