113
Overview
Overview
General Views of the Scales
FC06BBE-S(0CE)
No. Designation Order no.
for replacement
13 Toggle key for alphabetic input
14 On/off key
15 Weight display
16 Lug for attaching an antitheft
locking device
17 AC jack
18 Interface port
19 Level indicator
Not shown:
Dust cover for weighing platform 69 60FB01
Dust cover for display and control unit 69 60LP03
Protective caps and plugs (set) 69 B20009
No. Designation Order no.
for replacement
1 Display and control unit
2 Draft shield cover 69 LP 0002
3 Glass draft shield cylinder 69 14290
4 Weighing pan 69 LP 0004
5 Pan support 69 LP 0005
6 Shield disk 69 LP 0003
7 Leveling foot 69 B20005
8 Metrological ID label
(only on verified models or models acceptable
for legal metrological verification)
9 Tare key
10 Function keys
11 Print key
12 Keys for numeric input
