Configuring the Scale
Menu level 1
Menu level 2
Menu level 3
Factory setting
Menu level 4
Setup – 1 Scale functions 1 1 through 1 8 see previous page
Scale Menu
1 9 CAL key function 1 9 1 External calibration/adjustment** with
factory-set calibration weight
1 9 3 External calibration/adjustment** with
user-defined calibration weight
1 9 4 Internal calibration/adjustment
1 9 10 CAL key blocked
1 9 11 reproTEST
1 9 12
o
Selection mode
1 10 Calibration/adjustment 1 10 1
o
Calibrate, then auto adjust
sequence 1 10 2 Calibrate, then manual adjust
1 13 Tare/zero when power 1 13 1
o
On
is switched on 1 13 2 Off
1 15 isoCAL function 1 15 1 Off
1 15 2 Only adjustment prompt
1 15 3 On and reset application
1 15 5
o
On without resetting application
5 Interface 5 1 Baud rate 5 1 1 150 baud
5 1 2 300 baud
5 1 3 600 baud
5 1 4
o
1,200 baud
5 1 5 2,400 baud
5 1 6 4,800 baud
5 1 7 9,600 baud
5 1 8 19,200 baud
5 2 Parity 5 2 2 Space
5 2 3
o
Odd
5 2 4 Even
5 3 Number of stop bits 5 3 1
o
1
5 3 2 2
5 4 Handshake mode 5 4 1 Software
5 4 3
o
Hardware, 1 character after CTS
5 5 Communication 5 5 1
o
SBI
mode 5 5 2 XBPI
5 6 Network address 5 6 1
o
0
5 6 x 1 through 30
5 6 32 31
6 through 9 see next page
* = not applicable to verified scales
** = verified scales can only be calibrated, not adjusted
