Satec PM180 - Complex Measured Value (CMV); Sampled Value (SAV); Wye; Delta (DEL)

14
Attribute Name Attribute Type FC M/O/C Comments
the AnalogueValue may be present
for a given instance of DATA
q Quality MX M
t TimeStamp MX M
units Unit CF O
db INT32U CF O
d VISIBLE STRING64 DC O
Complex measured value (CMV)
Attribute Name Attribute Type FC M/O/C Comments
cVal Vector MX M
q Quality MX M
t TimeStamp MX M
units Unit CF O
db INT32U CF O
d VISIBLE STRING64 DC O
Sampled value (SAV)
Common data class is not supported.
WYE
Attribute Name Attribute Type FC M/O/C Comments
phsA CMV C
phsB CMV C
phsC CMV C
neut CMV C Signed with (*) where available
Delta (DEL)
Attribute Name Attribute Type FC M/O/C Comments
phsAB CMV C
phsBC CMV C
phsCA CMV C
Sequence (SEQ)
Attribute Name Attribute Type FC M/O/C Comments
c1 CMV M
c2 CMV M
c3 CMV M
seqT ENUMERATED MX M pos-neg-zero | dir-quad-zero
Harmonic value (HMV)
Common data class is not supported.
Harmonic value for WYE (HWYE)
Attribute Name Attribute Type FC M/O/C Comments
q Quality MX M
t TimeStamp MX M
phsAHar ARRAY[0..numHar] OF
Vector
MX M
phsBHar ARRAY[0..numHar] OF
Vector
MX O
phsCHar ARRAY[0..numHar] OF
Vector
MX O
numHar INT16U CF M numHar = 63 (no subharmonics)
