Satec PM180 - Phasors Met1;Phsrmmxu1; Half-Cycle Sequence and Imbalance Met1;Hcvmsqi1

26
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
TotW MV Total active power O
TotVAr MV Total reactive power O
TotVA MV Total apparent power O
TotPF MV Total power factor O
TotPFLag MV Total power factor lag E
TotPFLead MV Total power factor lead E
TotkWImp MV Total active power imported E
TotkWExp MV Total active power exported E
TotkVarImp MV Total reactive power imported E
TotkVarExp MV Total reactive power exported E
AuxV CMV Auxiliary voltage V4 E
AuxA CMV Auxiliary current I4 E
Hz MV Frequency O
AvPhV MV Average voltage phase to ground E
AvPPV MV Average voltage phase to phase E
AvA MV Average current E
ExtA WYE Phase currents, extended inputs
I1x-I3x
E (*) See WYE
ExtAuxA CMV Auxiliary current, extended input
I4x
E
AvExtA MV Average current, extended inputs
I1x-I3x
E
Phasors MET1/phsrMMXU1
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object name phsrMMXU1 M
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Measured values
PhV WYE Phase to ground voltages
(magnitude and angle)
O In 4LN3, 3LN3 and 3BLN3
wiring modes
PPV DEL Phase to phase voltages
(magnitude and angle)
O In 4LL3, 3LL3, 3BLL3,
3DIR2, 3OP2 and 3OP3
wiring modes
A WYE Phase currents (magnitude and
angle)
O
AuxV CMV Auxiliary voltage V4 (magnitude
and angle)
E
AuxA CMV Auxiliary current I4 (magnitude
and angle)
E
Half-cycle sequence and imbalance MET1/hcvMSQI1
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object name hcvMSQI1 M
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Measured values
SeqV SEQ Zero sequence voltage C
SeqA SEQ Zero sequence current C
