3.4.6 Logical nodes for metering and measurement
Energy counters MET1/engMMTR1
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object name engMMTR1 M
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Measured values
TotVAh BCR Apparent energy O Total
TotWh BCR Net real energy O Net
TotVArh BCR Net reactive energy O Net
SupWh BCR Real energy supply O Exported
SupVArh BCR Reactive energy supply O Exported
DmdWh BCR Real energy demand O Imported
DmdVArh BCR Reactive energy demand O Imported
Harmonic demands MET1/demMHAI1
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object name demMHAI1 M
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Measured values
ThdPhV WYE Voltage THD demand for phase to
ground
O In 4LN3, 3LN3 and 3BLN3
wiring modes
ThdPPV DEL Voltage THD demand for phase to
phase
O In 4LL3, 3LL3, 3BLL3,
3DIR2, 3OP2 and 3OP3
wiring modes
ThdA WYE Current THD demand O
TddA WYE Current TDD demand per IEEE
519
O
ThdAuxV MV Voltage THD demand for auxiliary
voltage input V4
E
ThdAuxA MV Current THD demand for auxiliary
current input I4
E
TddAuxA MV Current TDD demand for auxiliary
current input I4
E
Sequence of harmonics MET1/hrmMHAI1
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object name hrmMHAI1 M
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Measured values
HA HWYE Sequence of harmonics current O
HPhV HWYE Sequence of harmonics phase to
ground voltages
O In 4LN3, 3LN3 and 3BLN3
wiring modes
