Satec PM180 - Total Harmonics Met1;Ocvmhai1; 3-Second Total Harmonics Met1;Osvmhai1; Present Demands Met1;Demmmxu1

23
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
HPPV HDEL Sequence of harmonics phase to
phase voltages
O In 4LL3, 3LL3, 3BLL3,
3DIR2, 3OP2 and 3OP3
wiring modes
Total harmonics MET1/ocvMHAI1
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object name ocvMHAI1 M
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Measured values
ThdPhV WYE Voltage THD for phase to ground O In 4LN3, 3LN3 and 3BLN3
wiring modes
ThdPPV DEL Voltage THD for phase to phase O In 4LL3, 3LL3, 3BLL3,
3DIR2, 3OP2 and 3OP3
wiring modes
ThdA WYE Current THD O
HKf WYE K-Factor O
TddA WYE Current TDD per IEEE 519 O
3-second total harmonics MET1/osvMHAI1
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object name osvMHAI1 M
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Measured values
ThdPhV WYE Voltage THD for phase to ground O In 4LN3, 3LN3 and 3BLN3
wiring modes
ThdPPV DEL Voltage THD for phase to phase O In 4LL3, 3LL3, 3BLL3,
3DIR2, 3OP2 and 3OP3
wiring modes
ThdA WYE Current THD O
HKf WYE K-Factor O
TddA WYE Current TDD per IEEE 519 O
Present demands MET1/demMMXU1
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object name demMMXU1 M
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Measured values
PhV WYE Phase to ground voltage demands O In 4LN3, 3LN3 and 3BLN3
wiring modes
PPV DEL Phase to phase voltage demands O In 4LL3, 3LL3, 3BLL3,
3DIR2, 3OP2 and 3OP3
wiring modes
