Satec PM180 - Controllable Integer Status (INC); Binary Controlled Step Position Information (BSC); Binary Controlled Step Position Information (ISC); Controllable Analog Set Point Information (APC)

16
subVal CODED ENUM SV PICS_SUBST
subQ Quality SV PICS_SUBST
pulseConfig PulseConfig CF O
ctlModel CtlModels CF M
d VISIBLE STRING64 DC O
Controllable integer status (INC)
Attribute Name Attribute Type FC M/O/C Comments
ctlVal INT32 CO C
stVal INT32 ST M
q Quality ST M
t TimeStamp ST M
d VISIBLE STRING64 DC O
Binary controlled step position information (BSC)
Common data class is not supported.
Binary controlled step position information (ISC)
Common data class is not supported.
Controllable analog set point information (APC)
Common data class is not supported.
Single point setting (SPG)
Common data class is not supported.
Integer status setting (ING)
Common data class is not supported.
Analog setting (ASG)
Common data class is not supported.
Setting curve (CURVE)
Common data class is not supported.
Device name plate (DPL)
Attribute Name Attribute Type FC M/O/C Comments
vendor VISIBLE STRING255 DC M
model VISIBLE STRING255 DC O
location VISIBLE STRING255 DC O
Logical node name plate (LPL)
Attribute Name Attribute Type FC M/O/C Comments
vendor VISIBLE STRING255 DC M
swRev VISIBLE STRING255 DC M
d VISIBLE STRING255 DC M
confgRev VISIBLE STRING255 DC C LLN0 only
ldNs VISIBLE STRING255 DC C LLN0 only
