Satec PM180 - Logical Nodes for Control; Switch Controllers CTRL;CSWI1- CSWI16; Switch Control Interlocking Status CTRL;CILO1-CILO16; Relay Control Interlocking Status Met1;Blkcilo1-Blkcilo8

18
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
number
3.4.2 Logical nodes for control
Switch controllers CTRL/CSWI1- CSWI16
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object name CSWI1…CSWI16 M A configurable prefix can be
added to a LNName via the
device Bay Control Setup
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Status Information
Loc SPS Local control behavior O
Controls
Pos DPC Switch, general M
Switch control interlocking status CTRL/CILO1-CILO16
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object
name
CILO1…CILO16 M A configurable prefix
can be added to a
LNName via the device
Bay Control Setup
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Status Information
EnaOpn SPS Enable Open M
EnaCls SPS Enable Close M
Relay control interlocking status MET1/blkCILO1-blkCILO8
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object
name
blkCILO1…blkCILO8 M
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Status Information
EnaOpn1…EnaOpn8 SPS Enable Open:
Relay outputs RO1-RO8 (blkCILO1)
Relay outputs RO9-RO16 (blkCILO2)
Relay outputs RO17-RO24 (blkCILO3)
Relay outputs RO25-RO32 (blkCILO4)
Relay outputs RO33-RO40 (blkCILO5)
Relay outputs RO41-RO48 (blkCILO6)
Relay outputs RO49-RO56 (blkCILO7)
Relay outputs RO57-RO64 (blkCILO8)
M Blocking operation is
configurable via the
Relay setup. A relay can
only be unblocked via a
control setpoint.
EnaCls1…EnaCls8 SPS Enable Close:
Relay outputs RO1-RO8 (blkCILO1)
M Blocking operation is
confi
g
urable via the
