Satec PM180 - Event Flags Met1;Evfggio1 - Evfggio2; Setpoint Status Met1;Spggio1- Spggio2; Analog Inputs Met1;Aiggio1-Aiggio2

21
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
Loc SPS Local operation O
Controls
SPCSO1…SPCSO8 SPC Single point controllable status
output:
Relay outputs RO1-RO8 (boGGIO1)
Relay outputs RO9-RO16 (boGGIO2)
Relay outputs RO17-RO24 (boGGIO3)
Relay outputs RO25-RO32 (boGGIO4)
Relay outputs RO33-RO40 (boGGIO5)
Relay outputs RO41-RO48 (boGGIO6)
Relay outputs RO49-RO56 (boGGIO7)
Relay outputs RO57-RO64 (boGGIO8)
O
Event flags MET1/evfGGIO1 – evfGGIO2
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object
name
evfGGIO1, evfGGIO2 M
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Loc SPS Local operation O
Controls
SPCSO1…SPCSO32 SPC Single point controllable status
output:
Event flags FLG1-FLG32 (evfGGIO1)
Event flags FLG33-FLG64 (evfGGIO2)
O
Setpoint status MET1/spGGIO1- spGGIO2
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object name spGGIO1, spGGIO2 M
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Status Information
Ind1…Ind32 SPS General indication:
Setpoint SP1-SP32 (spGGIO1)
Setpoint SP33-SP64 (spGGIO2)
O TRUE = setpoint
operated
FALSE = setpoint
released
Analog inputs MET1/aiGGIO1-aiGGIO2
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object name aiGGIO1, aiGGIO2 M
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Measured Values
AnIn1…AnIn8 MV Scaled analog inputs:
Analog inputs AI1-AI8 (aiGGIO1)
Analog inputs AI9-AI16 (aiGGIO2)
O
