Satec PM180 - Harmonic Value for del (HDEL); Controllable Single Point (SPC); Controllable Double Point (DPC)

15
Attribute Name Attribute Type FC M/O/C Comments
numCyc INT16U CF M numCyc = 1
units Unit CF O
evalTm INT16U CF M evalTm = nominal period
frequency FLOAT32 CF M frequency = nominal frequency
d VISIBLE STRING64 DC O
Harmonic value for DEL (HDEL)
Attribute Name Attribute Type FC M/O/C Comments
q Quality MX M
t TimeStamp MX M
phsABHar ARRAY[0..numHar] OF
Vector
MX M
phsBCHar ARRAY[0..numHar] OF
Vector
MX O
phsCAHar ARRAY[0..numHar] OF
Vector
MX O
numHar INT16U CF M numHar = 63 (no subharmonics)
numCyc INT16U CF M numCyc = 1
units Unit CF O
evalTm INT16U CF M evalTm = nominal period
frequency FLOAT32 CF M frequency = nominal frequency
d VISIBLE STRING64 DC O
Controllable single point (SPC)
Applied to boGGIO and evfGGIO class nodes.
Attribute Name Attribute Type FC M/O/C Comments
ctlVal BOOLEAN CO C See notes below for relay operation
explanation
stVal BOOLEAN ST M
q Quality ST M
t TimeStamp ST M
d VISIBLE STRING64 DC O
pulseConfig PulseConfig CF O
ctlModel CtlModels CF M
Relay output operation depends on the configurable cmdQual attribute value (see
pulseConfig) and the relay operation mode configured in the device via the Relay Setup as
described in the following table.
cmdQual Relay operation
mode
Relay output operation
pulse Pulse/KYZ Pulse output. ctlVal = 1 – generates a pulse (normal/KYZ) with a duration
defined by the onDur attribute; ctlVal = 0 – no effect
pulse Latched/unlatched No effect
persistent Pulse/KYZ Pulse output. ctlVal = 1 – generates a pulse (normal/KYZ) with a duration
defined by the pulse width pre-configured in the device setup; ctlVal = 0 – no
effect
persistent Latched/unlatched Latched output. ctlVal = 1 – switch on, ctlVal = 0 – switch off
Controllable double point (DPC)
Applied to CSWI class nodes.
Attribute Name Attribute Type FC M/O/C Comments
ctlVal BOOLEAN CO C
stVal CODED ENUM ST M
q Quality ST M
t TimeStamp ST M
subEna BOOLEAN SV PICS_SUBST
