19
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
Relay outputs RO9-RO16 (blkCILO2)
Relay outputs RO17-RO24 (blkCILO3)
Relay outputs RO25-RO32 (blkCILO4)
Relay outputs RO33-RO40 (blkCILO5)
Relay outputs RO41-RO48 (blkCILO6)
Relay outputs RO49-RO56 (blkCILO7)
Relay outputs RO57-RO64 (blkCILO8)
Relay setup. A relay can
only be unblocked via a
control setpoint.
3.4.3 Logical nodes for switchgear
Circuit breakers CTRL/XCBR1- XCBR2
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object name XCBR1…XCBR2 M A configurable prefix can be
added to a LNName via the
device Bay Control Setup
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Status Information
Loc SPS Local control behavior M
OpCnt INS Operation counter M
AlmFlt SPS Breaker fault trip alarm E
Controls
Pos DPC Switch position M ST only
BlkOpn SPC Block opening M ST only
BlkCls SPC Block closing M ST only
Circuit switches CTRL/XSWI1- XSWI14
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object name XSWI1…XSWI14 M A configurable prefix can be
added to a LNName via the
device Bay Control Setup
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Status Information
Loc SPS Local control behavior M
OpCnt INS Operation counter M
SwTyp INS Switch type M
Controls
Pos DPC Switch position M ST only
BlkOpn SPC Block opening M ST only
BlkCls SPC Block closing M ST only
3.4.4 Logical nodes for protection related functions
Disturbance recorders MET1/drRDRE1-drRDRE8
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object name drRDRE1…drRDRE8 M
Common Logical Node Information
