Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Status Information
RcdMade SPS Recording made M Set to TRUE when at least
one disturbance waveform
is available for a read.
FltNum INS Fault number M Indicates the last waveform
series number available in a
disturbance recorder.
3.4.5 Logical nodes for generic reference
External (GOOSE) indication status CTRL/extGGIO1
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object name extGGIO1 M
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Status Information
Ind1…Ind128 SPS General indication O
Digital inputs MET1/biGGIO1-biGGIO8
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object name biGGIO1…biGGIO8 M
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
Status Information
Ind1…Ind16 SPS General indication:
Digital inputs DI1-DI16 (biGGIO1)
Digital inputs DI17-DI33 (biGGIO2)
Digital inputs DI34-DI48 (biGGIO3)
Digital inputs DI49-DI64 (biGGIO4)
Digital inputs DI65-DI80 (biGGIO5)
Digital inputs DI81-DI96 (biGGIO6)
Digital inputs DI97-DI112 (biGGIO5)
Digital inputs DI113-DI128
(biGGIO6)
O TRUE = closed
FALSE = open
Relay outputs MET1/boGGIO1-boGGIO8
Attribute name Attribute
type
Explanation/Value T M/O/C/E Comments
LNName Object
name
boGGIO1…boGGIO8 M
Common Logical Node Information
Mod INC Mode M
Beh INS Behavior M
Health INS Health M
NamePlt LPL Name plate M
