3. Send your setup to the device and save it to the device database.
6.3 Configuring Datasets
To review or configure the IEC 61850 datasets:
1. Select IEC 61850 Setup from the Meter Setup menu, and then click on the IEC 61850
Datasets tab.
2. Select a dataset you wish to view or configure in the “Dataset Reference” box. Select
“New Dataset” to create a new dataset.
3. To delete dataset members, uncheck the appropriate “Included” boxes. Uncheck all
dataset members to delete the entire dataset.
4. To add or change dataset members, click “Edit from file”, locate the PM180.icd template
file or a CID file you generated for your device, and click Open.
A full list of the available data objects and data attributed is displayed, where included
dataset members are checked.
To create a new dataset, select a logical device where the dataset will be located and
type a dataset name in the “Dataset Name” box.
Check the “Included” boxes for items you wish to be members of the dataset and click
OK.
To make easy selection of items across the list, use filters - functional constraints or/and
a selected logical device/logical node. Click “Filter checked” to see and revise a list of the
selected items.
5. Send your new setup to the device and save it to the device database.
