38
Item Value/Comments
Support of optional fields
Sequence number Supported, default = TRUE
Report time-stamp Supported, default = TRUE
Reason for inclusion Supported, default = TRUE
Dataset name Supported, default = TRUE
Data reference Supported, default = TRUE
Buffer overflow Supported, default = FALSE
EntryID Supported, default = FALSE
Conf-rev Supported, default = FALSE
Segmentation Not supported
Sending of segmented reports Not supported
EntryID Only the first 4 octets are used. Remaining octets must be 0.
Buffer size 5000 octets for each BRCB
Report Control Blocks predefined attribute values
RptID Datset OptFlds BufTm TrgOps
CTRL/LLN0$RP$URep01 Not defined 0x7C, 0x00 0 0x60
CTRL/LLN0$RP$URep02 Not defined 0x7C, 0x00 0 0x60
CTRL/LLN0$RP$URep03 Not defined 0x7C, 0x00 0 0x60
CTRL/LLN0$RP$URep04 Not defined 0x7C, 0x00 0 0x60
CTRL/LLN0$RP$URep05 Not defined 0x7C, 0x00 0 0x60
CTRL/LLN0$RP$URep06 Not defined 0x7C, 0x00 0 0x60
CTRL/LLN0$RP$URep07 Not defined 0x7C, 0x00 0 0x60
CTRL/LLN0$RP$URep08 Not defined 0x7C, 0x00 0 0x60
CTRL/LLN0$BR$BRep01 Not defined 0x7C, 0x00 0 0x60
CTRL/LLN0$BR$BRep02 Not defined 0x7C, 0x00 0 0x60
CTRL/LLN0$BR$BRep03 Not defined 0x7C, 0x00 0 0x60
CTRL/LLN0$BR$BRep04 Not defined 0x7C, 0x00 0 0x60
CTRL/LLN0$BR$BRep05 Not defined 0x7C, 0x00 0 0x60
CTRL/LLN0$BR$BRep06 Not defined 0x7C, 0x00 0 0x60
CTRL/LLN0$BR$BRep07 Not defined 0x7C, 0x00 0 0x60
CTRL/LLN0$BR$BRep08 Not defined 0x7C, 0x00 0 0x60
MET1/LLN0$RP$URep01 MET1/LLN0$DSet01Mx 0x7C, 0x00 0 0x60
MET1/LLN0$RP$URep02 MET1/LLN0$DSet02Mx 0x7C, 0x00 0 0x60
MET1/LLN0$RP$URep03 MET1/LLN0$DSet03Mx 0x7C, 0x00 0 0x60
MET1/LLN0$RP$URep04 MET1/LLN0$DSet05Mx 0x7C, 0x00 0 0x60
MET1/LLN0$RP$URep05 Not defined 0x7C, 0x00 0 0x60
MET1/LLN0$RP$URep06 Not defined 0x7C, 0x00 0 0x60
MET1/LLN0$RP$URep07 Not defined 0x7C, 0x00 0 0x60
MET1/LLN0$RP$URep08 Not defined 0x7C, 0x00 0 0x60
MET1/LLN0$BR$BRep01 Not defined 0x7C, 0x00 0 0x60
MET1/LLN0$BR$BRep02 Not defined 0x7C, 0x00 0 0x60
MET1/LLN0$BR$BRep03 Not defined 0x7C, 0x00 0 0x60
MET1/LLN0$BR$BRep04 Not defined 0x7C, 0x00 0 0x60
MET1/LLN0$BR$BRep05 Not defined 0x7C, 0x00 0 0x60
MET1/LLN0$BR$BRep06 MET1/LLN0$DSet08StInd 0x7C, 0x00 0 0x60
MET1/LLN0$BR$BRep07 MET1/LLN0$DSet09StFltNum 0x7C, 0x00 0 0x60
MET1/LLN0$BR$BRep08 Not defined 0x7C, 0x00 0 0x60
Report service information
Any predefined RCB attribute value may be written when RptEna is FALSE. Only existing data
sets (see Dataset model table) may be used for DatSet attribute changing. Internal events,
caused by data-change and quality-change trigger options only, result in immediate sending
of reports or buffering events for transmission (limited by a buffer size of 1000 bytes per
report).
