SATEL-EASy+
User guide
Version 1.33
13
1 NOTES FOR THE SATELLINE-3AS NMS USERS
1.1 How to add SATEL-EASy+ to SATELLINE-3AS NMS network
Since the SATEL-EASy+ factory settings (serial port as well as the radio settings) are always the
same, those should be set first as in the existing radio network to avoid conflicts.
Adding a new SATEL-EASy+ modem to SATELLINE-3AS NMS network:
Due to the settings of the SATEL-EASy+ modem, the new modem to network must be added in
the SATEL NMS PC software Design menu with the function “Add modem using hardware” and
then follow the requests in the to-do list.
Before this operation, it is recommended to check and adjust radio settings of the new SATEL-
EASy+, e.g., channel width (spacing), frequency, FEC status.
As the default serial baud rate of SATELLINE-3AS NMS diagnostics port (port 2) is 9600 bps, it is
recommended to use the same baud rate also with SATEL-EASy+ when adding it to an existing
3AS NMS radio network. When using this baud rate, the serial server advanced settings timeout
must be set to 10000 ms. Otherwise, the connection between NMS PC and SATEL-EASy + does
not work properly.
When creating a new network with SATEL-EASy+, NMS port baud rate can be used 115200 bps. In
this case the serial server timeout recommendation is 6000 ms.
SATEL Configuration Manager software:
SATEL-EASy+ does not support the terminal programming menu, therefore the modem settings,
like serial ports, configuration for a device without a display are managed by SATEL
Configuration Manager SW. Connection to SATEL-EASy+ from the software is done by using
Diagnostics (NMS) port of the radio, therefore CRS-NMS cable (YC0302) is required (Port 2 –
NMS). Diagnostic (NMS) port default settings are: port 2, 115200, 8N1.
Link to download SATEL Configuration Manager software: https://www.satel.com/support-and-
services/downloads/ (Note: version 1.15.10 or later)
