16 INSTALLATION
16.1 Installation of the radio modem
SATEL-EASy+ has four (4) fixing screw positions on its back side of the housing which can be
used to attach the modem to a structure or to accomplish a grounding connection.
Figure 1.4 Mounting screw positions
