6.9 Add RSSI to data
RSSI info "\02RSSI:-nnn dBm\03\0D\0A" will be concatenated to the end of serial port messages,
nnn is three digit decimal number.
6.10 Separate RX/TX-frequencies
Modem can transmit (TX-frequency) and receive (RX-frequency) on separate frequencies. The
switch between the frequencies introduces an extra 20 ms delay in the data transfer that must
be taken account when designing the system.
6.11 Radio compatibility
SATEL provides several radio compatibility modes:
• for selecting the optimum radio solution that fits the application
• for enabling the interoperability between devices made by different manufacturers
SATEL-EASy+ supports the original SATEL radio compatibility modes:
• SATELLINE-3AS (4FSK, FEC ON/OFF is selected by the separate FEC setting) (option 0)
• SATEL-8FSK-1 (8FSK/FEC OFF) (option 20)
• SATEL-8FSK-2 (8FSK/FEC ON) (option 21)
• SATEL-16FSK-1 (16FSK/FEC ON) (option 22)
• SATELLINE-2ASxE legacy mode (option 6)
Additional to the native SATEL radio compatibility modes, also the following radio compatibility
modes are supported by the 403 - 473 MHz frequency band product variants.
• Pacific Crest compatible modes:
o PacCrest-4FSK FEC ON/Scrambling ON) (option 1)
o PacCrest-4FSK FEC OFF/Scrambling ON (option 23)
o PacCrest-4FSK FEC OFF/Scrambling OFF (option 26)
o PacCrest-4FSK FEC ON/Scrambling OFF (option 28)
o PacCrest-GMSK FEC ON/Scrambling ON (option 2)
o PacCrest-GMSK FEC OFF/Scrambling ON (option 24)
o PacCrest-GMSK FEC OFF/Scrambling OFF (option 27)
o PacCrest-GMSK FEC ON/Scrambling OFF (option 29)
o PacCrest-FST 4FSK/FEC ON (option 5)
o PacCrest-FST 4FSK/FEC OFF (option 25)
o PacCrest-GMSK FEC ON, Scrambling ON, 4800 bps, 25 kHz (option 16)
o PacCrest-GMSK FEC OFF, Scrambling ON, 4800 bps, 25 kHz (option 17)
o PacCrest-GMSK FEC OFF, Scrambler OFF, 4800 bps, 25 kHz (option 18)
o PacCrest-GMSK FEC ON, Scrambler OFF, 4800 bps, 25 kHz (option 19)
