SATEL-EASy+
User guide
Version 1.33
17
16-FSK
28800 bps (25 kHz channel with FEC on)
14400 bps (12.5 or 20 kHz channel with FEC on)
Air Interface Encryption
AES128 (default), AES256 (DRM option)
Data Format
Asynchronous data
COMPLIANT WITH THE INTERNATIONAL STANDARDS
RF-requirements
EN 300 113-2 / FCC CFR47 section 90
EMC-requirements
EN 301 489-1 & -5 (8 kV contact, 15 kV air discharge)
Safety Standard
IEC 62368-1
Immunity
EN 61000-4-3 (2006) (10 V/m)
Vibration
MIL-STD-202G Test condition D
MIL-STD-202G Test condition F
MIL-STD-202H-213
3.2 SATEL-EASy+ 320-380 MHz variant (SATEL-TA46)
Available models and product codes:
• YM6030 SATEL-EASy+, without display, with AES128/AES256 encryption support
• YM6035 SATEL-EASy+, without display
• YM6060 SATEL-EASy+, with display, with AES128/AES256 encryption support
• YM6065 SATEL-EASy+, with display
RECEIVER
TRANSMITTER
Note!
Frequency Range
3
320-380 MHz
See note 3
Tuning range
60 MHz
Minimum RF Freq. Step
6.25 kHz
Channel Bandwidth
6.25 kHz, 12.5 kHz, 20 kHz, 25 kHz
Frequency Stability
±0.5 ppm
-40°C…+85°C (Reference
to +25°C)
Modulation
4-, 8-, 16-FSK, GMSK (Depending on
protocol or compatibility mode)
Due to different radio
interface protocol, 8-, 16-
FSK modulations cannot
be used under 3AS NMS or
any routing protocols.
Maximum Receiver Input
Power without Damage
+3 dBm
Maximum Receiver Input
Power without
Transmission Errors
-10 dBm
4FSK, 25 kHz, FEC ON
Sensitivity
1
BER = 10
-2
typ. -113 dBm
4FSK, 25 kHz, FEC ON
typ. -115 dBm
4FSK, 12.5 kHz, FEC ON
typ. -111 dBm
8FSK, 25 kHz, FEC ON
typ. -112 dBm
8FSK, 12.5 kHz, FEC ON
