SATEL-EASy+
User guide
Version 1.33
18
typ. -102 dBm
16FSK, 25 kHz, FEC ON
typ. -104 dBm
16FSK, 12.5 kHz, FEC ON
Blocking
1
BER = 10
-2
typ. -17 dBm
4FSK, 25 kHz, FEC ON
typ. -20 dBm
4FSK, 12.5 kHz, FEC ON
typ. -18 dBm
8FSK, 25 kHz, FEC ON
typ. -17 dBm
8FSK, 12.5 kHz, FEC ON
typ. -29 dBm
16FSK, 25 kHz, FEC ON
typ. -25 dBm
16FSK, 12.5 kHz, FEC ON
Intermodulation Response
Rejection
1
BER = 10
-2
typ. -35 dBm
4FSK, 25 kHz, FEC ON
typ. -37 dBm
4FSK, 12.5 kHz, FEC ON
typ. -36 dBm
8FSK, 25 kHz, FEC ON
typ. -36 dBm
8FSK, 12.5 kHz, FEC ON
typ. -44 dBm
16FSK, 25 kHz, FEC ON
typ. -41 dBm
16FSK, 12.5 kHz, FEC ON
CO-Channel Rejection
1
BER = 10
-2
typ. 8 dB
4FSK, 25 kHz, FEC ON
typ. 8 dB
4FSK, 12.5 kHz, FEC ON
typ. 10 dB
8FSK, 25 kHz, FEC ON
typ. 11 dB
8FSK, 12.5 kHz, FEC ON
typ. 21 dB
16FSK, 25 kHz, FEC ON
typ. 20 dB
16FSK, 12.5 kHz, FEC ON
DATA MODEM
Electrical Interface
Port 1: RS-232, Port 2: RS-232/485/422
Interface Connector
D-15 (female)
Data speed of Serial
interface
1200 115200 bps
Serial interface parameters
8N1, 8N2, 8E1, 8E2, 8O1, 8O2, 7N2, 7E1, 7E2, 7O1, 7O2
Data speed of Radio
Interface
4-FSK
19200 bps (25 kHz channel)
9600 bps (12.5 or 20 kHz channel)
14400 bps (25 kHz channel with FEC on)
7200 bps (12.5 or 20 kHz channel with FEC on)
8-FSK
28800 bps (25 kHz channel)
14400 bps (12.5 or 20 kHz channel)
19200 bps (25 kHz channel with FEC on)
9600 bps (12.5 or 20 kHz channel with FEC on)
16-FSK
28800 bps (25 kHz channel with FEC on)
14400 bps (12.5 or 20 kHz channel with FEC on)
Air Interface Encryption
AES128 (default), AES256 (DRM option)
Data Format
Asynchronous data
