Satel EASy+ - General for both Frequency Variants

SATEL-EASy+
User guide
Version 1.33
19
1 According to EN 300 113 V2.2.1 measurement setup.
2 Measured under normal ambient conditions, TA = 25 °C. When the device is used in different
environment, the results may change significantly. It is recommended to use external ESD
protection in demanding conditions.
3 Firmware rejects 405.925. 406.176 MHz frequencies. The frequency band is reserved
internationally for emergency transmitters as specified by FCC reference FCC 04-75
3.3 General for both frequency variants
GENERAL
Operating voltage range
+7 …+27.5 VDC (-15% / +20% *) **
Absolute MAX Voltage
+33 V (exceeding the value may damage the device)
Power Consumption
Receiver: MAX 2 W, typical <1.5 W @ 12 V
Transmitter @1 W output: MAX 6 W, typical <5.5 W @ 12 V
DTR OFF: MAX<50 mW, typical <10 mW @ 12 V
Temperature Ranges
-20 °C ... +55 °C Type Approval conditions
-30 °C ... +70 °C Functional**
-40 °C ... +85 °C Storage***
Vibration
≤ 25 G, up to 2 kHz sinusoidal
Antenna Connector
TNC female 50 Ohm
Construction
Aluminium housing
Size L x W x T / Weight
138.5 mm x 67 mm x 28.5 mm / < 350 g
*Note: As a result of new revision of safety standard IEC600001, voltage range is marked to a
label with tolerance limits.
** Using the device beyond this region the functionality cannot be guaranteed.
*** Recommended storage is at dry, room temperature
COMPLIANT WITH THE INTERNATIONAL STANDARDS
RF-requirements
EN 300 113-2 / FCC CFR47 section 90
EMC-requirements
EN 301 489-1 & -5 (8 kV contact, 15 kV air discharge)
Safety Standard
IEC 62368-1
Immunity
EN 61000-4-3 (2006) (10 V/m)
Vibration
MIL-STD-202G Test condition D
MIL-STD-202G Test condition F
MIL-STD-202H-213
