SATEL-EASy+
User guide
Version 1.33
15
3 SATEL-EASy+ TECHNICAL SPECIFICATIONS
3.1 SATEL-EASy+ 403-473 MHz variant (SATEL-TA40)
Available models and product codes:
• YM6015 SATEL-EASy+, without display
• YM6055 SATEL-EASy+, with display
• YM6010 SATEL-EASy+, without display, with AES128/AES256 encryption support
• YM6050 SATEL-EASy+, with display, with AES128/AES256 encryption support
RECEIVER
TRANSMITTER
Note!
Frequency Range
3
403-473 MHz
See note 3
Tuning range
70 MHz
Minimum RF Freq. Step
6.25 kHz
Channel Bandwidth
12.5 kHz, 20 kHz, 25 kHz
Frequency Stability
±0.5 ppm
-40°C…+85°C (Reference
to +25°C)
Modulation
4-, 8-, 16-FSK, GMSK (Depending on
protocol or compatibility mode)
Due to different radio
interface protocol, 8-, 16-
FSK modulations cannot
be used under 3AS NMS or
any routing protocols.
Maximum Receiver Input
Power without Damage
+3 dBm
Maximum Receiver Input
Power without
Transmission Errors
-10 dBm
4FSK, 25 kHz, FEC ON
Sensitivity
1
BER = 10
-2
typ. -113 dBm
4FSK, 25 kHz, FEC ON
typ. -115 dBm
4FSK, 12.5 kHz, FEC ON
typ. -111 dBm
8FSK, 25 kHz, FEC ON
typ. -112 dBm
8FSK, 12.5 kHz, FEC ON
typ. -102 dBm
16FSK, 25 kHz, FEC ON
typ. -104 dBm
16FSK, 12.5 kHz, FEC ON
Blocking
1
BER = 10
-2
typ. -17 dBm
4FSK, 25 kHz, FEC ON
typ. -20 dBm
4FSK, 12.5 kHz, FEC ON
typ. -18 dBm
8FSK, 25 kHz, FEC ON
typ. -17 dBm
8FSK, 12.5 kHz, FEC ON
typ. -29 dBm
16FSK, 25 kHz, FEC ON
typ. -25 dBm
16FSK, 12.5 kHz, FEC ON
Intermodulation Response
Rejection
1
BER = 10
-2
typ. -35 dBm
4FSK, 25 kHz, FEC ON
typ. -37 dBm
4FSK, 12.5 kHz, FEC ON
typ. -36 dBm
8FSK, 25 kHz, FEC ON
typ. -36 dBm
8FSK, 12.5 kHz, FEC ON
typ. -44 dBm
16FSK, 25 kHz, FEC ON
typ. -41 dBm
16FSK, 12.5 kHz, FEC ON
