34 User Manual SATEL
Pressing the  or  key in the graphic mode will display information on another set of
zones (see also description of the LEDs, p. 7).
The test results can be deleted by means of the CLEAR RESULTS function (TESTS
ZONES TEST CLEAR RESULTS).
5.14 Outputs control
If permitted by the installer, the control function can be started without user
authorization, upon pressing in turn the 8 and keys.
1. Enter the code and confirm with the
key
.
2. Press the 8 key. Depending on how the control panel has been configured by the installer:
 a group of outputs will be displayed – using the  and  keys, find the group which
includes an output, and then press the key to display the list of outputs,
 the list of controllable outputs will be displayed at once.
3. Using the  and  keys, find in the list the output whose status you want to change to
control the device connected to the output. The output status is presented by means of
symbols:
- output inactive (disabled),
- output active (enabled).
The output status can be presented according to the zone status. The displayed
symbols should then be interpreted as follows:
- zone not violated (the device controlled by output is inactive),
- zone violated (the device controlled by output is active).
The way of presenting the status of roller shutter outputs differs from how the status of
other outputs is presented (see: “Controlling the roller shutter outputs”).
5.14.1 Controlling the MONO SWITCH type of output
When the output is inactive:
– pressing the  key will activate the output for the time programmed by the installer,
– pressing the
key will allow you to program the time for which the output will be
activated upon the next pressing of the key.
When the output is active, pressing any digit key will turn the output off.
5.14.2 Controlling the BI SWITCH type of output
Pressing the
or  key will change over the output status. Additionally, when the output is
active, pressing any digit key will turn the output off.
5.14.3 Controlling the REMOTE SWITCH type of outputs
Depending on how the output has been programmed, pressing the or  key will activate
the output for the time programmed by the installer or change over the output status.
Additionally, when the output is active, pressing any digit key will turn the output off.
