SATEL PERFECTA 19
4. If you want to see the status of all zones which you can inhibit/unbypass, press or
. The numbers around the display enable identification of the zones. Use the
and keys to move the cursor. To inhibit/unbypass a zone, hover the cursor over it
r key. If you want to restore the previous way of presentation of the and press any numbe
zone list, press or .
5. Press to inhibit/unbypass zones.
6.11.2 Zone isolating
The isolated zone will remain bypassed until it is unbypassed by the user.
Enter the user menu and press in turn to run 2.ISOLATE function. The way of
in the procedure are identical to those used for inhibiting the
zones, but pressing any number key will change the displayed symbol to one of the following
symbols:
dicating the zone state and
– the zone is to be isolated,
– the zone is to be unbypassed.
6.12 Viewing the event log
Enter the user menu and press to run 5.EVENT LOG function. The last event that
occurred in the system will be displayed. In the upper line he display, the event
occurrence time is presented, and in the lower line – the event description. Press
of t
to see
some additional information related to the event in the lower line (e.g. the partition in which
at caused the event etc.). Press the event occurred, the zone th to see the information
upper line. The following characters are presented in
+ – test event sent via all defined transmission paths,
defined transmission paths.
related to reporting the event in the
square brackets:
space – event is not reported,
g – event sent via GPRS, SIM1 card,
G – event sent via GPRS, SIM2 card,
s – event sent via SMS, SIM1 card,
S – event sent via SMS, SIM2 card,
a – event sent via GSM voice channel, SIM1 card,
A – event sent via GSM voice channel, SIM2 card,
? – test event not sent via all
You can use the and keys to scroll the event log.
6.13 Setting the clock
1. Enter the user menu and press to run 6.SET TIME function.
2. Time according to the control panel clock will be displayed.
3. Enter the new time.
4. Press
to save new time.
5. Date according to the control panel clock will be displayed.
6. Enter the new date.
7. Press
to save new date.
