SECTION 1 SPECIFICATION
Page 1-2 SATO HT200e
PC card battery check (Memory card battery life is 2 years)
LCD Display 16 Character x 3 Line Alphanumeric
Keypad 11key Alphanumeric + 12 Function +Cursor Control + Enter
Dispense Stop Adjustment Panel (VR1)
Print Position Adjustment Panel (VR2)
Reflective Sensor Adjustment Panel (VR3) Don’t move
Dispense Sensor Adjustment Panel (VR4) Don’t move
LCD Brightness Adjustment Panel (VR5) PCB
INTERFACE CONNECTIONS
General Specification
Asynchronous ASCll
Half-duplex communication
Ready/Busy Hardware Flow Control
Pin 9, DTR Control
Pin 4, RTS Error Condition
X-On/X-Off Software Flow Control
Bi-Directional Communication
Data Transmission Rate 4800,9600,19200 bps
Character Format
1 Start Bit (fixed)
7 or 8 data bits (selectable)
Odd, Even or No Parity (selectable)
1 or 2 Stop bits (Selectable)
ELECTRICAL SPECIFICATIONS
Connector DB-9S
Cable
DB-9P (Male), 15m maximum length
For cable configuration, refer to Cable
Requirements appropriate to the RS232C
Protocol chosen.
Signal Levels
High = +5V to +12V
Low= -5V to -12V
PROCESSING
CPU 32bit RISC
NV memory 512K Bytes Flash ROM
Optional Memory 2MB SRAM PCMICA Card
