SATO HT200e - Page 17

SECTION 1 SPECIFICATION
SATO HT200e Page 1-3
DIMENSION
PRINTER
Size W 132mm X D 230mm X H 151mm (W 5.2" X D 9.2" X H 6")
Weight
2.5 kg (5.5lb) with Optional Battery Pack installed
2.4 kg (5.3lb) with AC Power Adapter installed
Adapter
Size W 130mm X D 117mm X H 28mm (W 5.2" X D 6" X H 1.1")
Weight 330g
Power Requirements
Input Voltage AC 110 / 230 V ±10%
Output Voltage and current DC8.4V 3.2A
Power Consumption Maximum 71 VA 43W
ENVIRONMENT
Operating Temperature 5 ～ 40 ゜ C 41 ～ 104 ゜ F
Strange Temperature -5 ～ 60 ゜ C 23 ～ 140 ゜ F
Operating Humidity 30% ～80% Non-condensing
Strange Humidity 30% ～90% Non-condensing
REGULATORY APPROVALS
Safety CE, TUV, UL, CSA, CCC
RFI/EMI FCC Class B
BARCODE SYMBOLOGIES
Liner EAN8, EAN13, UPC-A/E, NW-7, Inter-leaved 2 of 5
CODE39， CODE128B/C
MATRIX FONTS
X1 20 dots x 50 dots H
X2 8 dotsW x 20 dots H
X3 13 dotsW x 21 dots H
OCR-B 20 dotsW x 24 dots H
Price 16 dotsW x 24 dots H
POP1 28 dotsW x 48 dots H
POP2 48 dotsW x 68 dots H
POP3 26 dotsW x 56 dots H
