Section 7: Interface Specifications
TH2 Series Operator Manual Page 7-1
INTERFACE SPECIFICATIONS
This section presents the interface types and their specifications for the TH2 Series printers. These
specifications include detailed information to assist in the selection of the most appropriate method for the
printer to interface with the host.
The following information is presented in this section:
• 7.1 Interface types
• 7.2 Universal Serial Bus (USB) Interface
• 7.3 Local Area Network (LAN) Ethernet and Wireless LAN
7.1 INTERFACE TYPES
The TH2 Series has three types of Main PCBs. Each type of PCB is equipped with different interface types in
order to perform data communication with the host. These are described as follows.
1) Type 1: USB on-board
2) Type 2: USB and LAN on-board
3) Type 3: Wireless LAN on-board
.
Caution
Disconnect power before connecting or disconnecting interface cables. Never connect or disconnect
interface cables (or use a switch box) with power applied to either the host or printer. This may caused
damage to the interface circuitry in the printer/ host and is not covered by warranty.
Model
Interface Types
USB LAN
Wireless LAN
TH2 series (Type 1)
Yes
--
TH2 series (Type 2)
Yes Yes
-
TH2 series (Type 3) - - Yes
