SATO TH2 Series User Manual

Section 3: Configuration and Operation
Page 3-64 TH2 Series Operator Manual
3.7 PRINTER SETUP MENU (Cont’d)
Menu Description
NETWORK menu.
Enables the selection of 1.LAN or 2.WLAN.
Select 2.WLAN.
Note: Field Strength icon will only appear if WLAN is installed.
WLAN menu.
Enables the selection of 1.SSID or 2.Mode.
SSID, (Service Set IDentifier), is a name that identifies a particular 802.11 wire-
less LAN.
Displays input field with existing SSID and enables input of the new SSID.
The default SSID is SATO.
Allowed input:
0 to 32 character string. Input of more than 32 characters is not possible.
Notes:
• If the input field is left empty, Invalid will be displayed.
• If the value is acceptable, Saved will be displayed when enter button is
pressed.
MODE menu.
Enables the selection of 1.Infra or 2.Ad hoc.
The default selection is 2.Ad hoc.
