Scaime eNod4-D ETHERNET - Page 56

56
SCAIME Manual : NU-eNod4D-ETH-E-0418_216710-E.docx
Parameter Possible Value Description
Calibration Parameters
Range 0 – 10 000 000 Maximum weighing capacity
Division 1, 2, 5, 10, 20, 50 Difference between two consecutive indicated values
Decimals 0-7 Position of decimal point
Weight unit 4 visible char Weight measurement unit (g, kg, t, lb…) using for calibration
Time unit s, mn, h
Time unit using for calibration (eNod4-F and B). Only s and h can
be selected in eNod4-B.
Weight unit (display
flow rate)
g, kg, t Weight unit of flow rate which is displayed on main screen.
Time unit (display
flow rate)
s, mn, h Time unit of flow rate which is displayed on main screen.
Cut-off frequency
(display flow rate)
Cut-off frequency of flow rate which is displayed on main screen.
