SCAIME Manual : NU-eNod4D-ETH-E-0418_216710-E.docx

Physical

calibration

Allows creating relation between the weighing sensor and the physical values.

Number of loads 1, 2, 3 Number of calibration loads used during the physical calibration.

Load 1/2/3 1 – 1 000 000 Weight values corresponding to each calibration segment.
