Scanreco RC400 G3B User Manual

LED-display
Cable A
Cable C
Cable B
4.3 Central Unit G3B denition
The illustrations below aims to declare all entities mentioned in this document.
Activating the Central Unit G3B
TheCentralUnitG3BissuppliedthruCableAandrequiresexternalpowerswitching,seechapter
5.8 for further info.
The Central Unit G3B exists in 2 different versions; one with 2 cable outputs and one with 3 cable
outputs. Refer to chapter 5.8 for further info.
Document type Document number PageRev
Service Manual S071 C 12 of 46
