Scanreco RC400 G3B User Manual

Part number information:
Part no: No of outputs Type of connector
47753 8 AMP-JTP 4-pol
47961 8 Hirchmann GDM3009
1
1
1
2
3
1
4
2
5
3
6 7 8
CONNECTOR:
AMP-JPT 4-pol
CONNECTOR:
Hirchmann GDM3009
1
2
3
Cablespecication:
Cable Lenght Wires x Dim.
1-8 2 meters 3x0,5mm
4
3
1 = MODULE SUPPLY
1 = MODULE SUPPLY
1
1
2
2
3
3
2
3 = GND
3 = GND
1
2 = REGULATED SUPPLY
2 = REGULATED SUPPLY
WIRE:
WIRE:
Girder/cable alignment:
13.3 Standard valve cable kits for Sauer-Danfoss PVG-32
For connection of analogue functions for Sauer-Danfoss PVG-32 module
Central Unit type:
2010
2011
Document type Document number PageRev
Service Manual S071 C 44 of 46
