10 Online Programming mode
10.1 General description
The Scanreco RC 400 offers considerable possibilities for system constructors of hydraulically
drivenmobilecranesandmachines.Theprograminthecontrolsystemisverycomprehensive,
exibleandhasmanyadaptationpossibilitiesforspecicapplications.Thecontrolsystemoffers
simple programming of a number of functions which can easily be turned on or off or altered dur-
ing operation.
Toobtainthebestmanoeuvrecharacteristicsinthesimplestway,allprogramming/calibrationof
manoeuvre characteristics is made during operation (so called on-line programming). All program-
ming / calibration is made from the Portable Control Unit.
Programming is simple and does not require tools / instruments.
The installer/system designer is responsible for seeing that system is
used correctly and is responsible for any re-programming of the system
functions and the characteristics changes caused by this!
The system has 4 levels of authorisation:
Authorisation level 1. (Installer)
Change direction of analogue movement
Authorisation level 2.(Welltrainedinstaller,welltrainedservicepersonnel)
Change direction of analogue outputs A/B
Change start speeds for analogue outputs
Change stop speeds for analogue outputs
Change micro speed for analogue outputs
Change ramp speeds for analogue outputs
Authorisation level 3.(Welltrainedcraneandvalvemanufacturer,welltrained
system constructor)
Not declared in this document
Authorisation level 4. (Scanreco AB)
Not declared in this document
IMPORTANT SAFETY NOTE:
Inonlineprogrammingmode,whenyouselectaprogrammingstep,thesystemautomatically
activates the speeds of the corresponding selected lever. Speeds used are independent by SET
selected in the system and depend only by programming step in which you are.
EXAMPLE:
EvenifthesystemisworkinginSET1(SET1argumentisvalid),whenyouenterintheprogram-
mingmodestepno.8(SET2),thesystemwillactivateandworkwiththespeedsofSET2
Document type Document number PageRev
Service Manual S071 C 35 of 46
