Scanreco RC400 G3B - 13.3 Standard valve cable kits for HAWE

Part number information:
Part no: No of outputs Type of connector
48046 8 Hirchmann GDM3009
1
1
2
3
1
4
2
5
3
6 7 8
CONNECTOR:
Hirchmann GDM3009
1
2 3
Cablespecication:
Cable Lenght Wires x Dim.
1-8 2 meters 3x0,5mm
1 = PWM+ A
3 = PWM+ B
2 = PWM -
WIRE:
Girder/cable alignment:
1
2
3
13.3 Standard valve cable kits for HAWE
For connection of analogue functions for HAWE module
Central Unit type:
3010
3011
Document type Document number PageRev
Service Manual S071 C 45 of 46
