No Description Qty
1
Portable Control unit (PCU)
1
2
Central unit G3B (CU)
1
3
Battery Charger (10 - 30 VDC)
1
4
Battery cassette (NiMH 7.2 VDC)
2
5
Manoeuvre cable (10 meters)
1
3.3 Schematic overview of Scanreco RC-400 G3B
1
4
3
5
Below illustrations shows a typical system consistory for the G3B system
2
Document type Document number PageRev
Service Manual S071 C 9 of 46
