Scanreco RC400 G3B - 6.2 Central Unit LED-display

LED Display Meaning
Off,deactivated
Standbymode,nocommunicationlinkwithPCU
Standbymode,communicationlinkwithPCU
Communicationlinkviacable,ID-codeapproved
Communicationlinkviacable,ID-codenotapproved
Communicationlinkviaradio,frequencyhopping
Communicationlinkviaradio,frequencylockedonchannel1
Communicationlinkviaradio,frequencylockedonchannel2
Communicationlinkviaradio,frequencylockedonchannel3
Communicationlinkviaradio,frequencylockedonchannel4
Communicationlinkviaradio,frequencylockedonchannel5
Communicationlinkviaradio,frequencylockedonchannel6
Communicationlinkviaradio,frequencylockedonchannel7
Communicationlinkviaradio,frequencylockedonchannel9
Communicationlinkviaradio,frequencylockedonchannel10
Communicationlinkviaradio,frequencylockedonchannel11
Communicationlinkviaradio,frequencylockedonchannel12
Communicationlinkviaradio,frequencylockedonchannel13
Radio communication deactivated via program setting (WinSCI)
ID-programming procedure is active (See chapter 12 for further info)
ID-programming procedure rejected (See chapter 12 for further info)
Below table shows the variety of status indications available for both the Central Unit G2B and
G3B:
