13 G2B Standard Cable Kits
13.1 General description
Variousstandardcablekitsexisttosuitcertainsystemcongurationsandvalves/coils.
Typicallytwosetsofcablekitsarerequired,oneforpowersupplyanddigitalfunctionsandonefor
analoguefunctions,seebelowillustration.
1 = Left side; “Supply Cable kit” for power supply and digital functions.
2 = Right side; “Valve Cable kit” for analouge functions.
