Scanreco RC400 G3B - 9.3 Table; diagnostics data; 9.3.1 Position 1 - Analogue output status

9.3 Table / diagnosics data
9.3.1 Position 1 - Analogue output status
Press On-button once from position D:i – 0:0
D:i – 0:1 is displayed
As to determine the current status for all analogue outputs. Lever/joystick assignments and ana-
logueoutputstart,stoppandrampvalues.
Whileinthisposition,actuatingaspecicleverwillresultintheLED-displaypresentingwhich
outputthatisassigned,thedirectionandthecurrentrealtimevalue.
In example:
Leverisactuated,displayrespondsbyindicatingrelatedoutputfor1second
In example
1:A,2:A,3:A,4:A,5:A,6:A,7:A,8:A,1:b,2:b,3:b,4:b,5:b,6:b,7:b,8:b
Followed by the current value in correspondance to lever angle.
1-99,h:i*
*h:i indicating that 100% velocity is achieved
Position / LED Indication Meaning
D:i - 0:0 Default position
D:i - 0:1 Analogue output status
D:i - 0:2 Digital output status
D:i - 0:3 Digital Input status
D:i - 0:4 Error code Log
D:i - 0:5 Program save
D:i - 0:6 Program load
D:i - 0:7 CentralUnitrmwareversion
D:i - 08 PortableControlUnitrmwareversion
- Return to position 00
Document type Document number PageRev
Service Manual S071 C 32 of 46
