www.scheppach.com / service@scheppach.com / +(49)-08223-4002-99 / +(49)-08223-4002-58
GB
|
29
Transport tray (g. 22)
Push the transport tray (8) laterally into the holders
provided for this purpose using the guide bolts. Se-
cure these using the included splints.
Gear selector lever (g. 18)
Slide the gear selector lever (7) through the slot of
the switch plate. Fasten the gear selector lever on the
inside of the switch bracket using the screws (M8 x
30 mm).
On/off switch cable (g. 23)
Fasten the on/off switch cable using the included ca-
ble connectors.
m ATTENTION!
Always check before starting the engine:
• Check the fuel level and top it up if necessary
- the tank (21) should be at least half lled
• Make sure that the machine has sufcient ventila-
tion
• Make sure that the ignition cable (25) is secured to
the spark plug (13)
• Condition of the air lter
• Condition of the fuel lines
• The external bolt connections for tightness
Filling with fuel
Recommended fuel
Fill the only clean fuel with min. 90 octane and max.
5% bio-ethanol content in the fuel tank (21).
m NOTE
Fill tank to no more than 12.5mm (1/2”) below the
bottom of the ller neck to provide space for ex-
pansion.
Use only fresh and clean fuel.
m Attention!
Water or impurities in the petrol damage the fuel sys-
tem.
m Refuel in a well-ventilated area with the
stopped engine. If the engine has been running,
allow it to cool rst. Never refuel the engine in-
side a building where gasoline fumes may reach
ames or sparks.
Petrol is highly ammable and explosiv. You can
get burns or other serious injuries when handling
fuel.
• Switch off the engine and keep it away from heat,
sparks and ames.
• Refuelling only outdoors.
• Immediately clean up spilled petrol.
m WARNING
The vibration emission value can vary from the spec-
ied value during the actual use of the electric tool,
depending on the type and the manner in which the
electric tool is used. Try to minimise stress from
vibrations as low as possible. Some examples of
means for reducing the vibration stress are wearing
gloves while using the tool and limiting work time. In
the process all parts of the operating cycle must be
taken into account (such as times in which the elec-
tric tool is switched off or time in which it is switched
on, but is not running under a load).
Limit the noise and vibration to a minimum!
8. Unpacking
Open the packaging and remove the device carefully.
Remove the packaging material as well as the pack-
aging and transport bracing (if available)
Check that the delivery is complete.
Check the device and its spare parts for possible
damage caused by transportation. In the event of
complaints, you must contact the distributor without
delay. Claims at a later stage will not be accepted.
If possible, store the packaging until the warranty pe-
riod has expired
Before handling the device, make yourself familiar
with it by reading the operating instructions.
For accessories, consumables and spare parts, only
use original parts. Spare parts are available from
your stockist.
Include our item number, the device model and year
of manufacture in your order.
m Attention!
The device and packaging materials are not toys!
Children must not be allowed to play with plastic
bags, lm and small parts! There is a risk of swal-
lowing and suffocation!
9. Before starting the equipment
The following assembly instructions enable you to as-
sembly the machine in just a few minutes.
Steering rod (g. 21)
Align the drilled holes of the steering rod with the
drilled holes of the side parts and secure the steering
rod using the screws (pos. A M10 x 45 mm and pos.
B M10 x 25), washers, and nuts.
Wheels (g. 6)
Push the wheels (10) onto the wheel screws and fas-
ten them with the included washers and lock nuts
(M12).
