Assembly
22
09.00 | PGN-plus | Assembly and Operating Manual | en | 389296
Item Mounting PGN-plus
40 50 64 80 100 125
Side A
1 Mounting screw M3 M4 M5 M5 M6 M8
Max. depth of
engagement from
locating surface [mm]
for Variants IS/AS
6
9
11
16
12
18
15
18
14
16
20
20
2 Centering sleeve Ø5 Ø6 Ø8 Ø8 Ø10 Ø12
Side B
4 Mounting screw M2.5 M3 M4 M4 M5 M6
Mounting screw
according to standard
DIN EN ISO 4762
2 Centering sleeve Ø5 Ø6 Ø8 Ø8 Ø10 Ø12
Side C
5 Mounting screw M2.5 M3 M4 M5 M6 M8
Mounting screw
according to standard
DIN EN ISO 4762
Max. strength class 8.8
3 Centering sleeve Ø5 Ø6 Ø8 Ø8 Ø10 Ø12
Item Mounting PGN-plus
160 200 240 300 380
Side A
1 Mounting screw M8 M10 M12 M16 M20
Max. depth of engagement
from locating surface [mm]
for Variants IS/AS
20
20
20
20
25.5
23
31
31
38
31
2 Centering sleeve Ø12 Ø14 Ø16 Ø22 Ø28
Side B
4 Mounting screw M6 M8 M10 M12 M16
Mounting screw according
to standard
DIN EN ISO 4762
2 Centering sleeve Ø12 Ø14 Ø16 Ø22 Ø28
Side C
5 Mounting screw M8 M10 M12 M16 M20
Mounting screw according
to standard
DIN EN ISO 4762
Max. strength class 8.8
3 Centering sleeve Ø12 Ø14 Ø16 Ø22 Ø28
