 Change the message count from 1 to 2 to add a trigger and message setting on this port.
Set the trigger condition to issue the message periodically (P) every second
(00 hrs:00 minutes:01 seconds).
!
Set the message to request meter data from the relay. The 20METER message is a
special “20” message for SEL relays.
3. Use the COPY 1 ALL command to copy settings from Port 1 to Ports 2 through 6. In
Example 3, you do not copy to Port 7 because it has a long string message that you do not
want to re-enter. Use the SET A command to define a trigger condition (P00:00:01.0) on
Port 7 that periodically triggers a message to send a meter command (using 20METER
setting) to relays when the trigger condition exists, just like Ports 1 through 6.
You should see a screen similar to the following when you use the COPY command:
*>>COPY 1 ALL<ENTER>
COPY 1 ALL<ENTER>COPY 1 ALL<ENTER>
COPY 1 ALL<ENTER>
Copy settings from Port 1 to Port 2 (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Perform auto-configuration on Port 2 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Port 2 Settings Changed
Copy settings from Port 1 to Port 3 (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Perform auto-configuration on Port 3 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Port 3 Settings Changed
Copy settings from Port 1 to Port 4 (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Perform auto-configuration on Port 4 (Y/N) ? N<
N<N<
N<ENTER>
ENTER>ENTER>
ENTER>
Port 4 Settings Changed
Copy settings from Port 1 to Port 5 (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Perform auto-configuration on Port 5 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Port 5 Settings Changed
Copy settings from Port 1 to Port 6 (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Perform auto-configuration on Port 6 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Port 6 Settings Changed
Copy settings from Port 1 to Port 7 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Unable to write settings to Port 8: Internal Modem Installed
Copy settings from Port 1 to Port 9 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Copy settings from Port 1 to Port 10 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Copy settings from Port 1 to Port 11 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Copy settings from Port 1 to Port 12 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Copy settings from Port 1 to Port 13 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Copy settings from Port 1 to Port 14 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Copy settings from Port 1 to Port 15 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Copy settings from Port 1 to Port 16 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
*>>
Note:  You do not need to perform auto-configuration if all port devices are identical. However,
you may need to reset port IDs on all ports that settings are copied to, if port IDs were
different on each port.

