4-32 “Job Done” Examples - (Example 3) Date Code 20010518
SEL-2020 Instruction Manual
4. Define a command (GETDAT) that the RTU will send to the SEL-2020 to request meter
data (see Figure 4.5). Use SET U to define this user-defined command
(CMD1="GETDAT").
Your screen should show the following:
*>>SET U 11<ENTER>
SET U 11<ENTER>SET U 11<ENTER>
SET U 11<ENTER>
User settings for Port 11
Warning: setting CMD_EN=N will disable SEL-2020 commmands on this port
Enable SEL-2020 Commands (Y/N) CMD_EN = Y ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Command termination character CMD_CH = \00D ? <ENTER>
<ENTER><ENTER>
<ENTER>
General-Purpose User-Defined Input Commands
Number of general purpose commands (0-8) CMD_CNT = 0 ? 1
11
1<ENTER>
<ENTER><ENTER>
<ENTER>
Command String 1
CMD1 = ""
? GETDAT<ENTER>
GETDAT<ENTER>GETDAT<ENTER>
GETDAT<ENTER>
Special-Purpose User-Defined Input Commands
Enable use of special purpose commands (Y/N) STR_EN = N ? <ENTER>
<ENTER><ENTER>
<ENTER>
CMD_EN = N CMD_CH = \00D
CMD_CNT = 1
CMD1 = "GETDAT"
STR_EN = N
Save changes (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Port 11 Settings Changed
*>>
Notes:  Disable the SEL-2020 command set on this port because you don’t want the SEL-2020 to
recognize any message from the RTU, other than the “GETDAT” command you defined.
When you disable the SEL-2020 command set, the SEL-2020 prompts you for a
command termination character. The default is “\00D”, which is the ASCII string for
carriage return (<CR>).
! Enter CMD_CNT=1 to set one user-defined command.
" Set CMD1=GETDAT; the user-defined command the RTU will send to the SEL-2020.
# The SEL-2020 prompts you to enable special purpose commands TRANS, WRITE, and
READ. No special purpose commands are used in this example.

!
"
#
