The operating and configuration screens
These screens bring up the information and commands relating to the active menu.
They are divided into three zones:
an upper band common to all types of screens.
the central section in which the specific information on the selected menu appears.
a lower band.
15/07/09 19:10 :00 GS 1 Event archive Auto Faults Alarms
- 1 -
Electrical archive
- 2 -
Mechanical archive
-3 –
Event metering
Upper band
Indications
15/07/09 19:10 :00 GS 1 Welcome Auto Faults Alarms
Upper band
Central section
Lower band
Date of the system
Time of the system
Reference of the GS with
which the M.M.I. dialogues
Indication of the presence of a fault on the GS
concerned (flashing red)
Indication of the presence of an alarm on the GS
concerned (orange flashing)
Indication of the operating mode of the
GS concerned
Name of the active screen
