Appendix K – DGPS 465
The DGPS 465 unit receives RTCM corrections via UHF and transmits the corrections to the
DPS 200 system via serial line.
Physical Dimensions DGPS 465 unit
Width:......................................................................................................482 mm (19-inch rack)
Height: .................................................................................................................. 44.5 mm (1 U)
Depth: ..............................................................................................................................350 mm
Weight: ..................................................................................................................................3 kg
Colour:..............................................................................................................Front plate, black
Environmental Specification DGPS 465 unit
Enclosure material:.....................................................................................................Aluminium
Enclosure protection:...........................................................................................................IP-44
Operating temperature range: ......................................................................................0 to +55ºC
Operating humidity:...........................................................................Max. 95% non-condensing
Storage temperature range:...................................................................................... -20 to +60ºC
Storage humidity:...................................................................................................Less than 55%
Physical Dimensions 450 MHz antenna
Height: ...........................................................................................................................1400 mm
Net weight: .........................................................................................................................1.3 kg
Colour:................................................................................................................................ White
Connector type:..............................................................................................................N-female
The UHF antenna is a vertically polarised omnidirectional antenna.
Environmental Specification 450 MHz antenna
Enclosure material:...................................................................... Polyurethane coated fibreglass
Wind rating:...................................................................................................................150 km/h
Radio Frequencies
Antenna:............................................................................................................... 440 - 470 MHz
The configuration of the DGPS 465 unit, is as follows:
Line Type Format Data
Port1 RS-232 9600,N,8,1 9-pin male, for connecting to the radio control
port on the DPS 200 unit.
Port3 RS-232 9600,N,8,1 9-pin female, differential data port.
UHF NA NA N female connector.
RF from UHF antenna.
Table 29 Serial port and antenna configuration for DGPS 465
FSP ref.: A11213500XRBRA0
