Seatex DPS 200 - Figure 8 Cabinet Dimensions

Seatex DPS 200 Installation Manual, rev. 4 Appendix F – External remote cabinet
72
Mechanical Installation
Mount the cabinet by fastening the four screws at the bottom of the cabinet. The screw holes
stand out 3 mm to permit air circulation behind the cabinet.
Figure 8 Cabinet dimensions
Electrical Installation
Ø 8.5
400 mm
400 mm
35 mm
35 mm
FSP ref.: A11213500XRBRA0
