Seatex DPS 200 Installation Manual, rev. 4 Appendix G – Mounting without DPS 200 cabinet
77
Appendix G – Mounting without DPS 200
cabinet
A DPS 200 system that is not delivered with cabinet shall be mounted on attachment rails in a
standard 19-inch rack. Minimum depth of the rack is 600 mm.
The rack must be resiliently mounted, otherwise the warranty will be void.
The rack should have air inlet on top and bottom or ventilation splits on the sides. The DPS
200 unit has ventilation on the sides. Foreced ventilation may be required if the cabinet
contains several electronic modules.
Screened cables are connected to the back of the unit, directly on the rear panel or on a
connector block with screen terminals. All cables connected to the unit must be screened.
Make sure that the minimum antenna cable bends are not exceeded, see Appendix B.
Keyboard and mouse are connected on the rear panel. A PS2 or serial mouse (Com2) can be
used. Make sure that the keyboard screen is connected to chassis on the DPS 200 unit.
CAUTION
