Seatex DPS 200 Installation Manual, rev. 4 Installation
17
3.7.2 Serial lines
DPS 200 communicates with external equipment through RS-232 and RS-422 serial lines.
The number of serial lines with input of differential GPS corrections, is only limited by the
number of available communication ports. Output data are position, time and velocity to
navigation computers, dynamic positioning systems etc. No hardware or software handshake
is used on the serial lines.
The default configuration of serial lines for DPS 200 is:
Line Type Format Data
Com1
(front)
RS-232 _ Spare, for service personnel
Com2 RS-232 _ Spare
Com3
(internal)
RS-232 4800,N,8,1 DiffCorrLink
RTCM IALA Beacon receiver
Com5 RS-232 9600,N,8,1 DiffCorrLink
SCF(Seastar supercompressed)
Com6 RS-232 9600,N,8,1 DiffCorrLink
SCF(Seastar supercompressed)
Com7 RS-422 9600,N,8,1 Gyro input
NMEA_HDT
Com8 RS-422 9600,N,8,1 DP Interface
Output: DPGGA
Com9 RS-422 9600,N,8,1 DP Interface
Output: DPGGA
Com10 RS-422 4800,N,8,1 DP Interface
Output: GPGLL, VTG
Com11
(internal)
RS-232 19200,N,8,1 GPS/GLONASS Receiver GG24
Com12
(MRU port)
RS-422 _ Spare
Com4 RS-232 _ Spare
Com14 RS-232 _ Spare
Com15 RS-232 _ Spare
Com16 RS-232 _ Spare
Com17 RS-232 _ Spare
Com18 RS-232 _ Spare
Table 2 Configuration of serial lines for DPS 200
FSP ref.: A11213500XRBRA0
