Seatex DPS 200 Installation Manual, rev. 4 Appendix C - RG-213 specifications
53
Appendix C - RG-213 specifications
RG-CABLE
RG 213/U
INNER CONDUCTOR
Ø 7x0.76 MM COPPER STRANDED
INSULATION
Ø 7.3 MM PE
OUTER CONDUCTOR
BRAID
COPPER BARE
SHEATH
Ø 10.3 MM PVC-BLACK
ELECTRICAL PROPERTIES:
CHARACTERISTIC IMPEDANCE 50 OHM ±2
ATTENUATION AT 20º (dB 100 M)
10 MHz 1.8 500 MHz 16.2
20 MHz 2.8 800 MHz 21.5
50 MHz 4.4 1000 MHz 24.5
100 MHz 6.8
200 MHz 9.7
MECHANICAL PROPERTIES:
MINIMUM BENDING RADIUS 50 MM
WEIGHT ±154 KG/KM
COPPER WEIGHT 82 KG/KM
