4.2 Scope of delivery (seca 797)
4.3 Assembling the device
NOTE
• Use an assistant to perform the assembly.
• We recommend placing the components on the floor and only set-
ting the device in an upright position once you have fitted the mea-
suring rod and the column.
Tools required In addition to the scope of delivery, you require the following tools:
Item Component Pcs.
a
Weighing platform with column holder
1
b
Display head with display unit, display cable and connecting cable
1
c
Barcode scanner holder
1
d
Measuring rod
1
e
Column (with four pre-fitted screws)
1
f
Spacer sleeves
2
g
Slot-head screws
2
h
Cross-head screws
3
i
Lock washers
4
j
T20 hex key
1
k
Plug-in power supply unit
1
l
Instructions for use
1
Instructions for Use
seca
Measuring Device
a
b
d
e
f
g
h
i
j
k
l
c
Tool Size
Slot-head screwdriver 1x5.5 mm
Cross-head screwdriver PH 2
