101
MR-2312-SR12/
MR-2312-SW12
Smart Relay Module
Must be connected to a listed power-limited
source of supply
Contact rating FormC/ 28VDC per contact /
1A resistive load max, zoned
Current consumption standby 30mA / alarm
140mA
Contact rating FormC/ 28VDC per contact / 1A resistive load
max, zoned
Current consumption standby 30mA, alarm 140mA
MR-2300-LCDR/
MR-2300-LCDW
Remote LCD Annunciator
Standby 56mA / alarm 65mA
MR-2306-ATW 8 Zone Remote Annunciator Standby 35mA / alarm 90mA
MR-2300-PR Polarity Reversal and City Tie Module
City Tie power limited / 24VDC unfiltered / 250mA max
/14Ohms trip coil
Polarity Reversal power limited / 24VDC open / 12VDC at
3.5mA / 8.5mA max (shorted)
Polarity Reversal Supv. Terminal 24VDC (normal) / í24VDC (supervisory) / 0V
(trouble)
Polarity Reversal Alarm Terminal 24VDC (normal) / í24VDC (alarm) / 0V
(trouble)
Current Consumption standby 50mA / alarm 300mA (city tie in use) /
alarm 70mA (city tie not in use)
MR-2300T Remote Trouble Indicator Standby 35mA / alarm 35mA
Table 18 MR-2300 LED System Modules and Annunciators (Continued)
MR-2300 LED Series Modules and Annunciators
